Automatic Wood Based Panel Packaging Line

HALLMARK Has Manufacturing Wood Industry and 20+ years of experience under its belt, offering the widest selection of hydraulic components and solutions!

Request a Quick Quote

Automatic Wood Based Panel Packaging Line

The automatic packaging production line is used to realize the online detection and automatic packaging of finished boards cut according to the production line specifications.
The main functions of the automatic packaging line can meet the needs of automatic circumferential wrapping, automatic top protection, corner paper protection, and product long edge

Request a Quick Quote

Automatic Packaging Line Video

Hallmark Wood Based Panle Packaging Line

Here are our various types of Automatic Packaging Line and related equipment catalog

Photovoltaic Automatic Packaging
Electronic and Electrical Automatic Packaging Line
Papermaking Automatic Packaging Line
Fully Automatic Strapping Machine
Fully Automatic Rotating Winding Machine
PET Plastic Steel Strapping

Contact Our Support Team

Process Flow of Wood Based Panel Packaging Line

1.Wood Based Panel Packaging Line

The whole stack is turned over and turned, the top film is automatically placed, the vertical corner protectors on the four sides and the wrapping film are automatically placed, the top protective board is automatically placed, the long side is placed with horizontal corner guards for packaging, the short side is placed with horizontal corner guards and the bottom pad is packaged, Double package stacking, etc.

Consult Your Technical Expert

Parameter of Wood Based Panle Packaging Line

No	Item	Parameter
1	Plate Stack Width	1830mm-2135mm
2	Stack Length	2440mm-2745mmm
3	Stack Height	800mm-1000mm
4	Packing Quantity	20 stacks/h
5	Side guard Angle dimensions	80×50mm×50mm×4mm
6	Packing tape specifications	16mm×0.8~1.0mm

Send Us Your Inquiry Today

Wood Based Panel Surface Quality Inspection System (Visual Inspection)

Visual Inspection

The industrial Al detection model ADetector technologyis used to identify the boardsurface through a visual professional algorithm.Prompt-based learning is used toaccurately determine whether a defect meets the shipping standard.

2mm diameter rubber board, black spots, oll stains, sand leakage, large shavings and other defects;Cracks andnotches with a width of 2mm;The detection rate of the above board defects is more than 99%.

Production Process: belt conveying, visual inspection, automatic identification, data collectiongrading and palletizing,and off-line.

Machine Vision A-Detector Intelligent Algorithms

Precisegrasping, fast speed and good stability The software combines the object detection data andsuperimposes deeplearning to determine the defecttype more accurately.

Independent Research and Development of Light

Optical analysis is performed for special defects, and optical systems are developed.
High-brightness white light overcomes the interference caused by surface.

Quality Data Analysis

Filter data for unknown models and provide pre-trained models
The accuracy is high, and the detection results are accumulated and learned in real time.

Replacing Manual Inspection and Saving Costs

Standardize the industrial chain
Connect the front and back ends of the production line and conduct logistics-style equipment design

Experienced Team

The after-sales team returns regularly and is online 24/7
Professional management of customer equipment files

Equipment Disclosure

Equipment disclosure
Into new defects, the threshold setting is flexible and adjustable.
Quality control docking, real-time adjustment of testing standards.

WRAPPING MACHINE of Packaing Line

Protect the package with stretch film and make it water proof, damp proof and dust proof.

The automatic wrapping machine with rotating arm, LT300, is equipped with extensible polyethylene gripper, cutting and welding units.

The speed of ascent and descent of the reel holder, the rotation of the arm, the accelerations and decelerations are managed by inverter.

Full of safety fences with interconnected access doors and limit switch.

·Independent electric control cabinets, alarm lights, and with sound, installed in the electric control cabinet.

·Touch screen operation, winding layer number and number can be set.

·Photoelectric switch, from the dynamic measurement of the height of goods.

·Digital parameter setting: Cantilever speed, film frame lifting speed, film frame film speed.

·The machine is equipped with automatic, manual, side-shift function, better guarantee the operation of the packaging system.

·The workpiece around the need to install paper corner 4, and vertical installation.

STRAPPING MACHINE of Automatic Packaing Line

Protect the packaging with stretch film, making it waterproof,lake-proof and dust-proof.The rotating arm of this automatic wrapping machine isequipped with an extendable polyethylene clamp, cuttingand welding unit.

The inverter controls the lifting speed of the film rack, thespeed of the arm, the acceleration and reduction ratio.The safety fence connects to the limit switch on the door.

horizontal and vertical packagingVarious materials,convenient and fast.
Users can customize.

They are employed by many large, medium and smallfactories.

The strapping machine has the function of automatically adding padsNumber of pads: 60

Specifications of pads: 1220mm long x 60mm wide x 60mm high

Requirements for strapping: 4 strappings in the longitudinaldirection and 2 strappings in the transverse direction to achieveparallel-shaped packaging.

Automatically place paper corner guards when strapping

Corner guard dimensions: 100mm long x 50mm wide x 5mm thickCorner guard storage: 100
Working capacity: not less than 20 pallets/hour

Intelligent Inspection Board Line of Wood Based Panel Packaging Line

The equipment comes with dust cleaning system, whichdoesnot require manual dust removal for daily use.The visualinspection system has its own communicationanomalyprocessing system, which can prevent the unqualifiedboardfrom entering the superior board due to systemanomalies

The main function of the board inspection equipment is toautomatically inspect the boards in the production lineto ensure the quality of the product and the accuracy of thepackaging.
Various defect adjustment parameters are open tocustomersand customers can flexibly adjust according to theneeds ofeach supplier.

PLC Programmable Controlled:
Touchable screen operation, visual operation interface of the whole line, dual screen display at the incoming end outgoing the board end;

Soft poly roller brush, with upper and lower dust collection devices, can effectively clean the plate flour dust;Independent pressure regulating valve, the cylinder is individually adjusted and controlled, and the operation

Precision is High:
Buffer cylinder adjustment, increase cylinder linear guide rail, ensure the service life of the cylinder; The plate jointsurfa ce is made ofinsulating resin rubber plate to avoid damage to the contact point ofthe plate;Electric swing table device , precise drive control, positioninginduction plate, zero error in positioning;Dynamic balance high- precision correction roller, quenching galvanized treatment, wear-resistant and rust- proof;The tail device is electrically adjusted, the linear quide rail design is increased, the precision rack is fixed, and the stopposition is zero error; Separate cylinder locking devices are used on both sides for precise positioning;The dro p of the stacking position is 160mm, the smallest design drop in China at present, and the stacking is stablewhenstacking,so as to avoid jitter patterns on the board surface;
The lifting device adopts high- strength manganese steel rectangular pipe, with compact mechanism and stablelifting, which is suita ble for high-freq uency continuous operation and meets the smooth lifting of large-tonnagegoods.

Start An Order With Us

Packing Line of Wood Based Panel Packaging Line

1. PLC programmable control
2.Independent electric control cabinet, alarm light, and sound;
3.Photoelectric switch, automatic sensing of cargo height;
4. Digital parameter setting, touch screen operation, can setrelevant equipment transportation parameters; The machine isequipped with automatic mode and manual mode conversionto better ensure the operation of the packaging system:
5.Top lamination, effective dust and moisture prevention;
6. Automatic winding and rotating arm design to ensure overallflexibility of packaging; Suction cup vertical corner protectionmanipulator, cooperate with film wrapping machine forcircumferential packaging;
7.Automated strapping machine, to ensure the stability andtransportation safety of goods;

Start An Order With Us

Why Choose Hallmark's Automatic Wood Based Panel Packaging Line

Develop solutions, systems and products according to each customer's production and logistics strategy.

Our focus is on advanced technology, process innovation and raising awareness of our products and services.

Machinery safety, online monitoring, 24-hour after-sales service, equipment reliability performance, high efficiency.

Pre-sales and after-sales service, customer satisfaction. At Litaii Control, they are called trust.

Quality is a career, a mission, a vision.

Wood Based Panel Packaging Line of Automatic Packaing Line

A New Generation of DigitalIntelligent Platforms Contributes to Realizing Digital Operation &Maintenance, Lean Production, intelligent Security Protection.

The Flooring Packaging Line integrated with an Automated Storage & Retrieval System (ASRS) is a state-of-the-art solution for automating the packaging, storage, and retrieval of wood-based panels. This advanced system enhances efficiency, reduces manual intervention, and ensures seamless inventory management for various panel products such as MDF, plywood, and particleboard.

Automated Guided Vehicle (AGV) of Automatic Wood Based Panel Packing Line

Automated Guided Vehicles (AGV) an intelligent handling system designed for Flooring packaging line of wood-based panels (MDF, particleboard, OSB, etc.). It achieves high-precision and high-efficiency automated transportation through preset tracks, perfectly replacing traditional forklift operations.

✅ Efficient and Stable

24-hour continuous operation, speed up to 60m/min.
Failure rate <0.5%, far exceeding the reliability of manual handling.

✅ Accurate Positioning

Laser + encoder dual positioning, repeatability ±2mm.
Automatically align the packaging line interface to prevent plate misalignment.

✅ Flexible Adaptation

Modular design, can quickly switch between different specifications of plate handling.

✅ Intelligent Management

Real-time monitoring of operation data, support for remote diagnosis.

Start a Project With Us

Stretch Film Machine of Automatic Packaging Line

Tray Winding Machine

Diameter of the Turntable : 1650mm
Bearing Capacity of Turntable : 2000kg
Packaging Height :2400mm
Packing Size :L(600mm-1200mm)xW(600mm-1200mm)
Rotary Speed :0-12r/min

Self-Propelled Winding Machine

Minimum Packaging Size:W600mmxL600mmxH700mm
Packaging Height: 2200mm
Rotational Speed: 1-16r/min

·With safety baffle , automatic stop when encountering obstacles to ensure safety.
·Wrapping layers, operating speed, and film tension can be adjusted , withreliable performance and easy operation.
·Automatically packaging line measures the height of the goods by photoelectrie switch.
·Not limited by the size and weight of the pallet.

Know Detailed Information

Please Download Catalogue Here

Welcome To Visit Our Factory

HALLMARK is a Wood Industry manufacturer specializing in research and development, production, sales and service, with its own factory and 19 years extensive experience in manufacturing large production lines. Products are sold to Russia, Turkey, Egypt, Algeria, South Africa, Iran, India, Malaysia, Vietnam, the United States and other more than countries around the world.

Our Products include Wood Based Panel Packaging Line(MDF/HDF,Partical Board/Chip Board, Flooring,Lamination Board and other product ), Photovoltaic Automatic Packaging Line、Electronic and Electrical Automatic Packaging Line、Papermaking Automatic Packaging Line、Intelligent Inspection Board Line、Fully Automatic Strapping Machine、Fully Automatic Rotating Winding Machine、PET Plastic Steel Strapping and so on.
- Automatic Wood Based Panel Packaging Line

  Automatic Wood Based Panel Packaging Line
- Automatic Wood Based Panel Packaging Line

  Automatic Wood Based Panel Packaging Line

Wood Based Panel Packaging Line

Chipboard Laminate Board Packaging Line

As a leader in wood-based panel Packaging Line and Decorative panelPackaging Line、New Material Packaging Line.HallMark has successfully provided customized one-stop services for small and large brands for more than 16 years with our rich expertise and know-how.

Our well-established factory in Jiangsu Province, China and sales offices are located all over the world. We are passionate about our business and continue to push the limits of technology to provide quality, innovative and environmentally friendly product solutions to our many customers.

Start An Order With Us

Delivery of Wood Based Panel Packaging Line

Our team ensured that all components of the wood based packaging line were securely transported to your facility. We have taken every measure to guarantee the safety and integrity of the equipment during transit, adhering to the highest standards of handling and packaging.

Till now we have successfully set up many Packaging line Impregnation Line factories in the middle east, Southeast Asia, Central Asia, Vietnam etc.

FAQ of Wood Based Panel Packaging Line

Q What is the maintenance requirement for the Wood Based Panel Packaging Line?

1.Regular cleaning of conveyors and rollers.

2.Lubrication of moving parts.

3.Inspection of wrapping and strapping machines.

4.Checking sensors and control systems for accuracy.
Q What are the advantages of using a Wood-Based Panel Packaging Line?

Increased efficiency: Reduces manual labor and speeds up the packaging process.

Improved safety: Minimizes damage to panels during handling and transport.

Consistent quality: Ensures uniform packaging and wrapping.

Cost-effective: Reduces material wastage and operational costs.

Customizability: Adaptable to various panel sizes and packaging needs.
Q What types of wood-based panels can this packaging line handle
The packaging line can handle a variety of panels, including:
- MDF (Medium Density Fiberboard)
- HDF (High-Density Fiberboard)
- Plywood
- Particleboard
- Laminated boards
Q What is a Wood-Based Panel Packaging Line?

A Wood-Based Panel Packaging Line is an automated system designed to efficiently pack wood panels, such as MDF, plywood, particle boards, or other similar products. It ensures secure wrapping, stacking, and handling for safe transportation and storage.
