An automatic interior trim production line is a manufacturing system that produces interior trims for vehicles in an automated way. The interior trim refers to the parts of a vehicle's interior that cover the body panels, such as door panels, dashboard, seats, headliners, and carpeting.
| Specification | 200T | 350T | 400T | |
| Effective pressure | T | 200 | 350 | 400 |
| Effective Stroke | MM | 600 | 600 | 600 |
| Crank shaft deflection of the worktable | MM | 85 | 850 | 850 |
| Balance degrees of the upper and lower mould | MM | ±0.3 | ±0.3 | ±0.3 |
| Verticality of the upper and lower mould | MM | ±0.1 | ±0.1 | ±0.1 |
| Temperature control accuracy | ℃ | ±3 | ±3 | ±3 |
Working temperature | ℃ | 450 | 150 | 150 |
| The heating power shall be proper to ensure | ℃ | 135 | 135 | 135 |
| Range of pressure maintaining and supplementary pressing | Bar | ±2 | ±2 | ±2 |
1.The three-beam four-column structure is economical and practical.
2. The hydraulic control adopts an integrated cartridge valve integrated system, which reduces leakage points, ensures reliable operation and long service life.
3. The machine can realize two molding processes of constant pressure and fixed stroke, and has the function of holding pressure delay, and the delay time is adjustable.
4. The working pressure and stroke can be adjusted within the specified range.
5. It adopts button centralized control and has three operation modes: adjustment, manual and semi-automatic.
This series of hydraulic presses are suitable for drawing,bending,flanging,cold
extruding,blanking precesses for materials,straightening,press-in and forming precesses for powder and abrasive preducts,plastic and insulation materials.
1.Rich Experience and Professional Design
We have 19 years experience in Woodworking industry,also has many years exporting experience. Each equipment location,passage will be designed reasonably to meet safety production.
2.Competitive Price
HallMark has own factory,with the same configuration,the price is competitive.And we are familiar with the Chinese market,our suppliers provide high-quality cost-effective accessories.
3.Timely After-sale Service
We have over 15 skilled technicians engineers, 26 after-sales engineers will be sent to the customer's factory to assist in the installation and debugging of the Whole production line until it runs well,and asked for quick responses to customer questions within 8 hours.
4.One-stop Solution
We provide one-stop service, including market analysis and professional technical consultation,Short Cycle Press Line, Paper Impregnation Production Line, Wood Based Panel Production Line, Raw materials ,Equipment installation, personnel training,Professional after-sales service team,Renovation of old equipment,make turnkey projects.
5.Quality Control
Strict quality control of equipment in production and before leaving the factory, and a complete quality management system for purchased parts.Customers are always welcome to make videos or come to the factory to know the production status.
6.Customized
HallMark's engineer team will design the layout according to customer’s factory space and production requirements.
1.What is an automatic interior Molding Press Machine?
A: An automatic interior trim production line is a manufacturing process that produces interior trim parts for vehicles using automated machines and equipment.
2.What are the main machines used in automatic interior Molding Press Machine?
A: The main machines used in an automatic interior trim production line include a material feeding system, cutting machine, punching machine, hot press machine, trimming machine, and packaging machine.
3.What materials are used to produce interior Molding parts?
A: Materials used to produce interior trim parts include textiles, leather, synthetic materials, foam, and plastic.
4. What is the process of automatic interior Molding Press Machine?
A: The process of automatic interior trim production involves the following steps: material feeding, cutting, punching, hot pressing, trimming, and packaging.
5.What are the advantages of an automatic interior Molding Press Machine?
A: The advantages of an automatic interior trim production line include higher production efficiency, reduced labor costs, improved product quality and consistency, and better safety for workers.
